SUN 6K-SG04LP3 |6kW | Three Phase | 2 MPPT | Hybrid Inverter | Low Voltage Battery
48V low voltage battery, transformer isolation design
6 time periods for battery charging/discharging
Max. charging/discharging current of 240A
Max.10pcs parallel
DC couple and AC couple to retrofit existing solar system
Support storing energy from diesel generator
100% unbalanced output, each phase; Max. output up to
50% rated power
Max. 10pcs parallel for on-grid and off-grid
operation; Support multiple batteries parallel
6 time periods for battery charging/discharging
Max. charging/discharging current of 120A
Max.16pcs parallel
DC couple and AC couple to retrofit existing solar system
Support storing energy from diesel generator
24/48V low voltage battery, safe and reliable
Unique Smart Load application and Grid peak shaving function
4ms fast transfer from on-grid to off-grid mode, ensuing the traditional fixed frequency air conditioner works well
Battery Type : Lead-acid or Lithium-ion
Battery Voltage Range (V) : 40~60V
Max. Charging Current (A) : 150A
Max. Discharging Current (A)
Max. DC Input Power (W) : 7800W
PV Input Voltage (V) : 550 (160-800)
MPPT Range (V) : 200-650
Start-up Voltage (V) 160V
PV Input Current (A) : 13A+13A
Rated AC Output and UPS Power (W) 6000W
Output Frequency and Voltage : 50/60Hz; 3L/N/PE 220/380, 230/400Vac (three phase)
